CC2652P CC2652 BLE Simplelink 2.4G Zigbee2MQTT Thread Home Assistant Coordinator Router CC2652P USB Dongle Stick
US $215.65
Latest Update :
Brand Vendor :
Product Id : AwwGwwdsdEdhdURU
Posted : Mon, 16 May 2022 10:47:00 -0400
☑ More Details
*Please kindly take a note that prices can change at any time. We may receive commissions when you click our links and make purchases.

Extraordinary quality CC2652P CC2652 BLE Simplelink 2.4G Zigbee2MQTT Thread Home Assistant Coordinator Router CC2652P USB Dongle Stick with low price directly from producer. All round world wide free shipping available for 75$ purchase. Available at very limited amount, you have to reserve now before sold out.

Term:

CC2652P CC2652 BLE Simplelink 2.4G Zigbee2MQTT Thread Home Assistant Coordinator Router CC2652P USB Dongle Stick Details & Specification :

Item Specifications
Origin CN(Origin)
Type Furniture Leg
modname=ckeditor

NOTE: The item is not available now, it will be available in about 1 month later.


ABOUT CC2652P

Pre-flashed with latest Zigbee2MQTT firmware -- 20211207 version.

Tiny USB stick or dongle, adapter of development board for 2.4G multiprotocol RF


FEATURES:


1. 2.4GHz multiprotocol RF development board(OpenThread,Zigbee,BLE,IEEE802.15.4,6LoWPAN and proprietary) based on TI CC2652P1FRGZR chip


2. Communicates with the host computer via the common CH340E USB-UART bridge

3. cJTAG debug header, flashed firmware or debug with JTAG
3. Self-programming via the TI serial bootloader with bootloader bit enabled

4. SMA antenna port for an external antenna with personal choice

5. General LEDs(Red--Power on indication  Green--DIO7 Blue--DIO6)


6. General Buttons(BTN1--DIO13<Bootloader-enable>  BTN2--DIO14 RST--nRESET)

7. IO  breakouts with 2.0mm pitch holes for connecting peripheral device

8. Low power LDOs


9. ESD protections with USB interface

10. easy to use with Koenkk's zigbee2mqtt
11. easy to use with TI's OpenThread border router


TESTING:


1. RF performance testing



2. Frequency spectrum testing


3. Function testing

4. QC pass


BOM Manufaturer:


1. Inductor -- muRata
2. Capacitor -- muRata/AVX/Samsung
3. Resistors -- FH
4. Crystal oscillator -- TXC/TKD
5. LEDs -- Orient


FLASHING:


1. Via USB interface with bootloader enable:
    A. flash firmware using TI Flash Programmer 2:
    press BTN1 and keep holding --> click the Reset button --> wait a  few seconds --> release BTN1 button --> Flash programmer 2 operation

    B. flash firmware using cc2538-bsl.py

2. Via cJTAG interface with TI debugger tools


FIRMWARE:


   The dongle comes stitched with coordinator firmwares, you can flash it with router or other types firmware via USB with bootloader enable condition.


ABOUT CC2652

The coordinator firmware is pre-flashed.
Supports: coordinator,router
Confirmed working with ZHA, ZIGBEE2MQTT


OVERVIEW:


Tiny USB stick or dongle, adapter,development board for 2.4G multiprotocol RF
such as Openthread border router, Zigbee2MQTT adapter, Contiki 6LowPAN, BLE, Simplelink.

FEATURES:
1. 2.4GHz multiprotocol RF development board(OpenThread,Zigbee,BLE,IEEE802.15.4,6LoWPAN and proprietary) based on TI CC2652R1FRGZR chip
2. Communicates with the host computer via the common CH340E USB-UART bridge
3. cJTAG debug header, flashed firmware or debug with JTAG
3. Self-programming via the TI serial bootloader with bootloader bit enabled
4. SMA antenna port for an external antenna with personal choice
5. General LEDs(Red--Power on indication  Green--DIO7 Blue--DIO6)
6. General Buttons(BTN1--DIO13<Bootloader-enable>  BTN2--DIO14 RST--nRESET)
7. IO  breakouts with 2.0mm pitch holes for connecting peripheral device
8. Low power LDOs
9. ESD protections with USB interface
10. easy to use with Koenkk's zigbee2mqtt
11. easy to use with TI's OpenThread border router
12. Confirmed working with ZHA,ZIGBEE2MQTT
13. Compatible with LAUCH-XL CC2652R1 from TI

TESTING:


1. RF performance testing

2. Frequency spectrum testing

3. Function testing
4. QC pass


BOM:


1. Inductor -- muRata
2. Capacitor -- muRata/AVX/Samsung
3. Resistors -- FH
4. Crystal oscillator -- TXC/TKD
5. LEDs -- Orient


FLASHING:


1. Via USB interface with bootloader enable:
    A. flash firmware using TI Flash Programmer 2:
    press BTN1 and keep holding --> click the Reset button --> wait a  few seconds -->     release BTN1 button --> Flash programmer 2 operation

    B. flash firmware using cc2538-bsl.py

2. Via cJTAG interface with TI debugger tools


DIMENSION:


5.5cm * 2.3cm * 1.3cm

FIRMWARE:


The dongle comes stitched with coordinator firmwares of zigbee2mqtt, you can flash it with router or other types firmware via USB with bootloader enable condition.
https://github.com/Koenkk/Z-Stack-firmware/tree/master/coordinator/Z-Stack_3.x.0/bin
